4 Term HD Relay
Current Rating 75 AMP
Product Specs
| Item Condition | Aftermarket Part |
| Description | Power Relay |
| Volt | 12 |
| Amps | 75 |
| Terminal ID 2 | 30 |
| Terminal 2 Size | M5-0.8 |
| Terminal ID 3 | 85 |
| Terminal 3 Size | 6.3mm x 0.8mm |
| Terminal ID 4 | 86 |
| Terminal 4 Size | 6.3mm x 0.8mm |
| Terminal ID 5 | 87 |
| Terminal 5 Size | M5-0.8 |
| Cap Composition | Plastic |
| Contact Config | Single Pole, Single Throw (SPST) |
| Duty Cycle | Continuous |
| Includes | Mounting Bracket |
| No Of Terminals | 4 |
| Plated Terminals | FALSE |
| Resistance Type | Coil Only |
| Resistance | 80 ohms |
|
Normally Open |
Replaces These Part Numbers
| Arrowhead | 240-01073 |
| Bosch | 0332002150, 0332002150315, 0332002150BLK |
1 Year Warranty
